Honda | GCV Series | OHV | 201cc | 2.59 In. x 2.32 In.| Recoil | Vertical | No Flywheel Brake
$294.00
Regular price
$294.00
Sale price
$294.00
Regular price
Unit price
per
Shipping calculated at checkout.
GCV200LAG5B
Couldn't load pickup availability
Honda GCV engines offer a quiet, yet powerful and lightweight combination for a variety of demanding applications. Ideal for residential mowers and pressure washers, these engines pack a punch.
| Equipment Type | Engine (Vertical) |
| Air Cleaner Type | Dry (Paper) |
| Bearing Type | Standard |
| Bore | 2.59-In. |
| CARB Approval For California | No |
| Carburetor | Float |
| Choke Control | Remote Rod |
| Compression Ratio | 8.0:1 |
| Cooling System | Air Cooled |
| Crankshaft | G5-Type |
| Crankshaft Diameter | .875 In. (7/8) |
| Crankshaft Length | 1.37-In. |
| Crankshaft Output | Vertical |
| Crankshaft Rotation (From PTO Shaft Side) | Counterclockwise |
| Cylinder Bore | Aluminum Alloy |
| Cylinders (Qty.) | 1 |
| Engine Displacement | 201 cc |
| EPA Compliant | Yes |
| Fuel Filter | In-Line |
| Fuel Tank & Capacity | Yes, 0.96 qt |
| Governor System | Centrifugal Mechanical |
| Ignition System | Transistorized Magneto |
| Item No_ | GCV200LAG5B |
| Lubrication System | Splash |
| Max. RPM | 3600 |
| Muffler Included | Yes |
| Net Power Output | 5.6 HP |
| Net Torque | 9.4 Ft-Lbs. |
| Oil Capacity | 0.42 Qt |
| Product Dimensions L X W X H - In. (mm) | 16.3 X 13 X 13.1-In. |
| Product Weight | 34 |
| Starter Type | Recoil |
| Stroke | 2.32 In. |
| Throttle Control | Fixed |
